IB880 - Socket 479 Pentium M SBC
with Intel 855GME 5.25-inch SBC with VGA/LAN, CRT/LVDS/TMDS
IB888 Small SBC 5.25 inch size
(Click to enlarge)

IB880 SPECIFICATIONS

CPU
Intel® Pentium® M processor
CPU Voltage
0.700V~1.708V
System Speed
Up to 2.0GHz
CPU External Clock
400MHz
Green /APM
APM1.2
Chipset
Intel® 82855GME chipset
GMCH: 82855GME, 732-pin Micro-FCBGA
ICH4: 82801DB 421-pin BGA
BIOS
Award BIOS; Supports ACPI function
Cache
1M or 2M Level 2 cache depending on CPU
Memory type
Two DDR DIMM socket, supports DDR200/266/333MHz, max. 2GB, supports ECC function
VGA
Intel® 82855GME integrated VGA
Supports CRT & LVDS (24-bit), TMDS
LAN
ICH4 integrated LAN controller (10/100Mb) + optional Intel® 82541GI Gigabit Ethernet controller
IDE
Built-in ICH4, IDE1, 2 (Ultra DMA 33/66/100)
Audio
ICH4 built-in audio controller + AC97 Codec ALC650
2-watt amplifier





Features:
- Supports Pentium® M / Celeron® M processors
- Up to 2.0GHz+, 400MHz FSB
- DDR DIMM x 2, max. 2GB
- Integrated VGA, shared memory, CRT/LVDS/DVI/TV-out
- Integrated 10/100 BaseT and Intel® Gigabit LAN
- Watchdog timer, Digital I/O
- Type 2 CF socket, Mini PCI slot
- PCI slot, 2 x SATA, 4 x USB, 4 x seria
l



LPC I/O
Winbond 83627HF: IrDAx1 Parallel x1, COM1 (RS-232), COM2 (RS-232/ RS422/RS485), FDC 2.88MB (3 Mode Support), Hardware monitoring (3 thermal inputs, 4 voltage monitor inputs, VID0-5, 2 fan headers)
Secondary I/O
Fintek F81216D: COM3 & COM4 (RS-232)
RTC/CMOS
ICH4-M built-in
Battery
Built-in lithium battery
Keyboard Controller
Built-in Winbond 83627HF
USB
Pin header, supports 4 ports, USB 2.0
Compact Flash
Supports Type II CF card socket via IDE2 slave channel
Serial ATA
SiL3512; supports 2 ports
Digital I/O
4 in, 4 out
Watchdog Timer
256 levels
Expansion Slots
1 PCI slot (supports 2 Bus Masters)
1 Mini PCI slot
Power Connector
20-pin ATX type
System Voltages
+5V, +12V, -12V, 5VSB
Dimensions
203mm x 146mm (7.99" x 5.74")

Environmental Factors:
Operating Temperature
0°C~60°C (32°F~140°F)
Storage Temperature
-20°C~80°C (-4Ā°F~176°F)
Relative Humidity
10%~90% (non-condensing)

Ordering Information

IB880 - 5.25", Socket 479 for Pentium/Celeron M, 855GME, ICH LAN, GMCH VGA
IB880F - 5.25", Socket 479 for Pentium/Celeron M, 855GME, ICH LANx1 + 82541GI GbE LANx1, GMCH VGA, DVI
IB880-C6 - 5.25", Intel Celeron M 600Hz (Zero-Cache), 852GM, ICH LAN, GMCH VGA (heatsink included, Fanless, Click here to see picture of heatsink)
IB880F-P11 - 5.25", Intel LV Pentium M 1.1GHz, 855GME, ICH LANx1 + 82541 GbE LANx1, GMCH VGA, DVI (heatsink/fan included)
ICooL001- 22mm Low-Profile Pentium M CPU Heatsink/Coole
IPWRA001-60W - Power adaptor
